Oki C650 User Manual

Management of this machine
- 229 -
6 Create user information based on the LDAP server information.
Input the LDAP key from which each value is obtained.
 Display name: Set the LDAP key to obtain the display name of user information.
 Mail address: Set the LDAP key to obtain the E-mail address of user information.
 Language code: Set the LDAP key to obtain the language code of user information.
 Group: Set to assign users to a group automatically. Set the LDAP key to obtain the assigned
group name. When a group with a group name defined by the same text string as the acquired text
exists in this machine, each group is assigned. When it does not exist, a group with the group name
of acquired text string is automatically created and assigned.
 Card ID: Set the LDAP key to acquire a card ID to use for the IC card authentication. When not
using IC card authentication, you do not need to input anything.
 PIN: Set the LDAP key to to acquire the PIN to use for PIN authentication. If you do not use PIN
authentication, you do not need to input anything.
 User Name: Set the LDAP key of the user name registered in the LDAP server.
The default value for user name is the LDAP key "sAMAccountName" for a Windows server.
Users using a Windows server do not need to change this setting.
 Cache authentication information: Set whether authentication information is temporarily stored in this
machine. The factory default setting is [Disable] (Do not save temporarily). When [Enable] is set,
user authentication can be performed even when communication with the LDAP authentication
server is not available due to a communication breakdown, etc., so this machine can be used
continuously.
 Validity period of cache authentication information: Displayed when [Cache authentication
information] is set to [Enable]. Set the validity period of the temporarily saved authentication
information in this machine on a daily basis. The setting range is 1 to 2000 days. After the set
number of days, authentication with temporarily stored information will not be available any more.
7 Click [Submit].
8 Click [Role Assignment Regulations].
Define regulations for automatically assigning roles to LDAP users.
9 Click [Add] to add new role assignment regulations.

Oki C650 Specifications

General

Duplex printing	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB connector	USB Type-A
USB 2.0 ports quantity	1
Printer fonts	PCL
Maximum duty cycle	100000 pages per month
Recommended duty cycle	8000 - 100000 pages per month
Page description languages	Epson FX, IBM ProPrinter, PCL 5c, PCL 6, PDF, PostScript 3
Mobile operating systems supported	Android
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	1940 sheets
Paper tray 2 input capacity	530 sheets
Total number of input trays	4
Multi-Purpose tray input capacity	100 sheets
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6, B7, B8
Maximum ISO A-series paper size	A4
Product color	White
Market positioning	Home & office
Internal memory	3000 MB
Processor family	ARM Cortex-A9
Sound pressure level (standby)	32 dB
Sound pressure level (printing)	54 dB
Storage temperature (T-T)	10 - 32 °C
Operating temperature (T-T)	-10 - 43 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1150 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	840 W
Maximum copy resolution	- DPI

Weight and Dimensions

Depth	430 mm
Width	395 mm
Height	290 mm
