4
Featu res Section 1-1
1-1 Features
The CQM1-B7A@@ Interface Unit incorporates the B7A transmission
operations for the CQM1H/CQM1 I/O Unit.
The following five models of CQM1H/CQM1 B7A Interface Unit are avail-
able.
Each Unit can be connected to the same number of points on 16-point
B7A Link Terminals as provided by the Unit. For example, two B7A Link
Terminal Units with 16 input points each can be connected to a CQM1-
B7A13.
The transmission delay time can be switched between STANDARD (19.2
ms rated) or RAPID (3 ms rated).
The data processing when a transmission error occurs can be switched
between HOLD (see note 1) and LOAD OFF (see note 2).
The CPU treats the B7A Interface Units as the equivalent number of
points. It can handle remote I/O equipment, such as switches and lamps,
without recognizing communications.
Note 1. HOLD: When an error occurs, the input bit status immediately prior to the
error is held.
2. LOAD OFF: When an error occurs, all input bits turn off.
The B7A Link Terminal is a terminal board that incorporates a communication
function, connects to external I/O devices, and communicates with a PC over
a single cable, thus reducing wiring effort.
Differences Between
CQM1-B7A01 and
CQM1-B7A21
CQM1-B7A21 is an upgraded version of the CQM1-B7A01 and can replace
the CQM1-B7A01.
The features listed in the table below have been added to the CQM1-B7A21.
Note CQM1-B7A01 is no longer in production. Use the upgraded CQM1-B7A21.
Model No. of points
Input Output
CQM1-B7A21 16 16
CQM1-B7A13 32 0
CQM1-B7A03 0 32
CQM1-B7A12 16 0
CQM1-B7A02 0 16
Item CQM1-B7A01 CQM1-B7A21
Transmission delay time STANDARD only STANDARD/RAPID
switchable
Transmission error
processing
HOLD HOLD/LOAD OFF switchable
