Nomenclature Section 3-3
3-3 Nomenclature
Front View
Side View
Ready indicator (green, lit when the Unit is rec-
ognized as the Temperature Control Unit)
Word number indicator (orange, lit when two words are
used and not lit when a single word is used)
Terminal screws: M3
(Optimum tightening torque: 0.5 N • m)
Slide lockFunction DIP switch (SW1)
CoverTerminalsSlide lock
