Bit Number Allocation Section 3-2
3-1-3 Terminal Arrangement
3-2 Bit Number Allocation
3-2-1 Word Allocation
Output words are allocated according to the mounting order (from left to right)
of the Units. Consecutive two output words are allocated to the Analog Output
Unit.
Indicators
Input terminal 1
Input terminal 2
Input terminal 3
Input terminal 4
Protective
ground terminal
Power supply
cable
Terminal screws: M3
Word 000
Word 001
Word 100
Word 101
Word 102
Word 103
Word 104
