Connecting Devices Section 1-3
1-3 Connecting Devices
1-3-1 CPU
The G730 Interface Unit connects to the following CPUs.
Note The number of points includes the CPU internal 16 input points (one word).
Therefore, the actual maximum numbers of points usable by the G730 Inter-
face Unit are 112 points (7 words), 240 points (15 words), and 496 points (31
words) respectively.
1-3-2 G730 Remote Terminal (Slave)
The following G730 Remote Terminals can be connected to a G730 Interface
Unit.
For more information about the G730 Remote Terminal, refer to the I/O Termi-
nal Series Catalog (X044).
Name Model Max. I/O Points (see note)
CQM1H-series CQM1H-CPU11 256 (16 words)
CQM1H-CPU21
CQM1H-CPU51 512 (32 words)
CQM1H-CPU61
CQM1-series CQM1-CPU11-E 128 (8 words)
CQM1-CPU21-E
CQM1-CPU41-EV1 256 (16 words)
CQM1-CPU42-EV1
CQM1-CPU43-EV1
CQM1-CPU44-EV1
Model I/O type I/O points
G730-RID04 Relay input (DC) 4
G730-RIA04 Relay input (AC)
G730-ROC04 Relay output
G730-ROC04-A Relay output (with error detection function)
G730-VID04 DC input, NPN (common +)
G730-VOD04 Transistor output, NPN (common –)
G730-ROC08 Relay output 8
G730-AOM08 Relay output (power MOS FET)
G730-VID08 DC input, NPN (common +)
G730-VID08-1 DC input, PNP (common –)
G730-VOD08 Transistor output, NPN (common –)
G730-VOD08-1 Transistor output, PNP (common +)
G730-ROC16 Relay output 16
G730-AOM16 Relay output (power MOS FET)
G730-VID16 DC input, NPN (common +)
G730-VOD16 Transistor output, NPN (common –)
