229
Appendix A
Specifications
Standard Specifications
The standard specifications of the CQM1-LSE01/LSE02 conform to those of SYSMAC CQM1H/CQM1-series
PCs.
Performance Specifications
Item CQM1-LSE01 CQM1-LSE02
Input No. of analog input points 1
Input range Voltage input 1 to 5 V, –9.999 to 9.999 V, –5 to 5 V
Current input 4 to 20 mA
Input
impedance
Voltage input 1 MΩ min.
Current input 10 Ω
Linearity ±0.1% FS ±1 digit max. with input sampling speed set to slow
±0.5% FS ±1 digit max. with input sampling speed set to fast
PC output code Signed binary (–9999 to 9999)
Sampling time 0.3 ms with input sampling speed set to fast and 0.6 ms with input sampling
speed set to slow
Sampling period 1 ms with input sampling speed set to fast and 2 ms with input sampling speed
set to slow
Operation processing time 5 ms
External control input TIMING/GATE, ZERO, ZERO RESET, RESET
No. of occupied words 1 input word and 1 output word
Moni-
tor out-
put
Voltage output --- –9.999 V to 9.999 V
Output linearity --- ±0.1% FS
Output resolution --- 1/8192
Output refresh period --- 0.5 s
Output response time --- 0.5 s
Permissible load resis-
tance
--- 10 kΩ min.
Insulation method Photocoupler insulation between input terminals and PC signals and between
input terminals and output terminals.
Dielectric strength 500 VAC for 1 minute between input terminals and output terminals
1,000 VAC for 1 minute between I/O terminals and FG
Current consumption 380 mA max. at 5 VDC 450 mA max. at 5 VDC
Dimensions 32 x 110 x 107 (W x H x D) mm
Weight 230 g max.
