178
Featu res Section 1-1
1-1 Features
• When the Linear Sensor Interface Unit is used in a system, linear sensor
input signals received by the Unit are converted into appropriate numeric
values according to preset scaling values.
• The Linear Sensor Interface Unit compares the scaled conversion data
with the four comparison set values (HH, H, L, and LL), ensuring the ease
of object discrimination.
• The four timing hold modes that are synchronized with the external signal
input allow free setting of the input data sampling point and easy retrieval
or control of desired data.
• The CQM1-LSE02 can convert input data into voltage output, which can
be used as data for external monitoring.
• The teaching function enables the Linear Sensor Interface Unit to use
actual input as scaling and comparison set values, thus ensuring the easy
adjustment.
• The zero point (measurement standard point) can be forced, which allows
relative object measurement.
• A ladder program can be used to enable the CQM1-LSE02 to have volt-
age output. The ladder program used with the CQM1-LSE02 enables the
output voltage to correspond to the data.
• The Programming Console can be used to easily set the Linear Sensor
Interface Unit to its initial values.
Linear Sensor Interface
Units
Model Type
CQM1-LSE01 Standard
CQM1-LSE02 With monitor output
