218
List of Commands Section 7-2
2. After confirming that the sign and the set value that the input word is set to
is correct, set 0000 to the output word.
3. The scaled conversion data or comparison result will stored in the input
word.
Note The Linear Sensor Interface Unit acknowledges the start or end of a com-
mand through a change in the output word value. When “0000” is set to the
parameter by the setting command, for example, even if “0000” is set at the
end of the command, the command doesn’t end because there is no change
in the output word value, not allowing scaled conversion data or comparison
result to be set in the input word. To end the command, set a value other than
the one set to the parameter. However, that the value will be reflected on the
monitor output if the Unit is used in the set data D/A output mode. Therefore,
when using the Unit in the set data D/A output mode, be sure to select a value
which will not affect peripheral devices.
7-2 List of Commands
The following commands can be used to set the initial parameters through the
Programming Console.
7-3 Commands and Responses
7-3-1 Operation Mode A Set
This command is used to set the following operation mode data.
• Data input
• Timing hold
• Input type
• Monitor output
The above items will be stored in the nonvolatile memory and will not be lost
after the Unit is turned OFF.
Command Command
code
Meaning Reference
page
Operation mode A set C000 Used to set operation mode A. 218
Operation mode A read C100 Used to read the settings of operation mode A. 219
Operation mode B set C200 Used to set operation mode B. 220
Operation mode B read C300 Used to read the settings of operation mode B. 221
Scaling value set C4** Used to set a scaling value. 222
Scaling value teach C5*0 Used to execute scaling value teaching. 223
Scaling value read C6*0 Used to read a scaling value. 223
Set value set C7** Used to set a set value. 224
Set value teach C8*0 Used to execute the set value teaching. 225
Set value read C9*0 Used to read a set value. 225
Hysteresis set CA00 Used to set hysteresis. 226
Hysteresis read CB00 Used to read the hysteresis. 226
Present value read CC00 Used to read the present scaled conversion data. 227
