116
Nomenclature Section 2-1
2-1 Nomenclature
Front View
Left Side View
Indicator
Terminal screws: M3
I1+
I1
V1+
V1
I2+
I2
V2+
V2
DA021
Indicator
Output terminal 1
Output terminal 2
Power supply cable
(Connect to Analog Power Supply Unit)
Indicator
JT1 setting pin
JT2 setting pin
Power supply cable
The green indicator of the Unit will
be lit if the Unit starts normally.
