165
Appendix A
Specifications
CQM1-SEN01 Sensor Unit
CQM1-TU001 Remote Console
E3X-MA11 Optical Fiber Photoelectric Module
Note The 10-ms OFF-delay timer function can be turned OFF.
Item Specification
Input points 4 max.
Current consumption 600 mA max. at 5 VDC (supplied from Power Supply Unit).
Input response time 8 ms max.
Insulation resistance 20 MΩ min. at 500 VDC between FG terminal and all signal terminals.
Dielectric strength 1,000 VAC at 50/60 Hz for 1 minute between FG terminal and all signal terminals.
Noise immunity 1,500 V (peak to peak) with a pulse width of 100 ns to 1 µs and a 1-ns rising edge.
Vibration resistance 10 to 150 Hz, 0.15-mm double amplitude for 80 min. each in X, Y, and Z directions.
Shock resistance
100 m/s
2
three times each in X, Y, and Z directions.
Ambient temperature Operating: 0° to 55°C
Storage: –20° to 75°C
Operating ambient humidity 10% to 90% with no condensation
Grounding Ground Sensor Unit at a resistance of less than 100 Ω
Enclosure rating Enclosed mounting
Dimension (mm) 32 × 110 × 120 (W × H × D)
Weight 160 g (Module excluded)
Display READY (green); output (orange)
Item Specification
Cable length 3 m
Power supply voltage 5 VDC (supplied from Sensor Unit)
Current consumption 60 mA max.
Ambient temperature Operating: 0° to 55°C
Storage: –20° to 75°C
Operating ambient humidity 10% to 90% with no condensation
Enclosure rating Enclosed mounting
Dimension (mm) 52.9 × 145 × 16.5 (W × H × D)
Weight 165 g including 3-m cable
Item Rating
Light source (wavelength) Red LED (660 nm)
Power supply voltage 9 VDC (supplied from Sensor Unit)
Current consumption 50 mA max.
Response time 500 µs max.
Timer function 10-ms OFF-delay timer (see note)
Indicators Operation indicator (orange) and stability operation indicator (green)
Teaching monitor Indicators (operation indicator and stability operation indicator)
Output mode Light ON and Dark ON (selectable)
Dimension (mm) 28.1 × 17.8 × 62.1 (W × H × D)
Weight 23 g
