6
Word Allocation Section 1-4
Output
Note Combine B7A Interface Units and B7A Link Terminals with equal transmission
delay times.
Transmission errors will occur if the transmission delay times used in the com-
bination are not equal.
Do not connect B7A Link Terminals with 10 points and I/O mixed points. Con-
nect only 16-point transmission models.
1-4 Word Allocation
The CPU treats the B7A Interface Unit as an equivalent number of connected
I/O Units. The words allocation is identical to that for I/O Units, with inputs and
outputs allocated from left to right.
Name Model Transmission delay time
Screw terminal model B7A-R6@@1 STANDARD (19.2 ms)
B7AS-R6@@1
B7A-R6@@6 RAPID (3 ms)
B7AS-R6@@6
Module model B7A-R6A52 STANDARD (19.2 ms)
B7A-R6A57 RAPID (3 ms)
PC connector models B7A-R@A@3 STANDARD (19.2 ms)
B7A-R@A@8 RAPID (3 ms)

Omron CQM1 Specifications

General

Model	CQM1
I/O Capacity	Up to 256 I/O points
Programming Language	Ladder Logic
Timer/Counter	128 timers/counters
Operating Temperature	0 to 55°C
Humidity	10 to 90% RH (non-condensing)
Power Supply	24 VDC or 100-240 VAC
Communication Ports	RS-232C
Memory Capacity	3.2K words
Instruction Set	Basic and advanced instructions
Memory	RAM (battery-backed)
Program Memory	3.2K words
Storage Temperature	-20 to 75°C
