Page #108 background image
5-6
Note 1. The value will be set in 0.001-Ω increments if the resistance is less than 10 Ω and 0.01-Ω
increments if the resistance is 10 Ω or over.
Note 2. The default setting for this parameter is the standard phase-to-neutral resistance of the maxi-
mum applicable motor.
H Setting the Motor No-load Current (n110)
Set the motor no-load current in percentage based on the rated current of the Inverter as 100%.
Contact the manufacturer of the motor for the motor no-load current.
This parameter is used as a vector control constant. Be sure to set the parameter correctly. This set
value is used for slip compensation as well.
n110
Motor No-load Current Register 016E Hex Changes during
operation
No
Setting
range
0 to 99 (%) Unit of
setting
1% Default setting See note.
Note The default setting for this parameter is the standard no-load current of the maximum applicable
motor.
Basic Operation
Chapter 5

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Omron SYSDRIVE 3G3MV SERIES and is the answer not in the manual?

Omron SYSDRIVE 3G3MV SERIES Specifications

General IconGeneral
ModelSYSDRIVE 3G3MV SERIES
CategoryInverter
Input Frequency50/60 Hz
Output Frequency0.1 to 400 Hz
Cooling MethodForced Air Cooling
Input Voltage200 to 240 VAC, 380 to 480 VAC
Horsepower Range0.1 to 15 HP
Power Range0.1 to 11 kW
Overload Capacity150% for 60 seconds
Braking UnitBuilt-in
Protection FunctionsOvercurrent, Overvoltage, Undervoltage, Overheat
CommunicationRS-485
Ambient Temperature-10 to 50°C
Storage Temperature-20 to 65°C
Humidity5 to 95% RH (non-condensing)
Vibration5.9 m/s² or less
Voltage Class200V, 400V
