Omron SYSDRIVE 3G3MV SERIES User Manual

5-18
5-6-4 Setting Frequency References through Key Sequences
The following description provides information on parameters related to frequency ref-
erence settings through key sequences on the Digital Operator
H Frequency Reference Setting/Display Unit Selection (n035)
• Set the unit of frequency reference and frequency-related values to be set or monitored in n035
through the Digital Operator.
• The frequency reference value will be set in 0.01-Hz increments if the frequency is less than 100 Hz
and 0.1-Hz increments if the frequency is 100 Hz or over.
n035
Frequency Reference
Setting/Display Unit Selection
Register 0123 Hex Changes during
operation
No
Setting
range
0 to 3,999 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 Less than 100 Hz: 0.01-Hz increments
100 Hz or over: 0.1-Hz increments
1 0.1% increments (Max. frequency: 100%)
2 to 39 1-rpm increments (number of motor poles)
40 to 3,999
Unit setting
The value to be set or monitored at max. frequency
jjjj
Three digits
Decimal place
Note To display 50.0 for example, set the value to 1500. (See note.)
Note The unit of setting of each parameter and monitor item below varies with the decimal place.
Parameters
n024 to n032: Frequency references 1 through 8 and inching frequency command
n120 through n127: Frequency references 9 through 16
Monitor Items
U-01: Frequency reference monitor
U-02: Output frequency monitor
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
