Omron SYSDRIVE 3G3MV SERIES User Manual

5-30
5-10 Multi-function I/O
5-10-1 Multi-function Input
The 3G3MV incorporates seven multi-function input terminals (S1 through S7). Inputs
into these terminals have a variety of functions according to the application.
H Multi-function Input (n050 through n056)
n050
Multi-function Input 1 (S1) Register 0132 Hex Changes during
operation
No
Setting
range
1 to 33 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 1
n051
Multi-function Input 2 (S2) Register 0133 Hex Changes during
operation
No
Setting
range
1 to 33 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 2
n052
Multi-function Input 3 (S3) Register 0134 Hex Changes during
operation
No
Setting
range
0 to 33 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 3
n053
Multi-function Input 4 (S4) Register 0135 Hex Changes during
operation
No
Setting
range
1 to 33 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 5
n054
Multi-function Input 5 (S5) Register 0136 Hex Changes during
operation
No
Setting
range
1 to 33 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 6
n055
Multi-function Input 6 (S6) Register 0137 Hex Changes during
operation
No
Setting
range
1 to 33 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 7
n056
Multi-function Input 7 (S7) Register 0138 Hex Changes during
operation
No
Setting
range
1 to 35 (for 26, see note 1 and for 27,
see note 2)
Unit of
setting
1 Default setting 10
Note 1. Set value 26 is supported by 5.5- and 7.5-kW Inverters only.
Note 2. Set value 27 is supported by Inverters up to 3.7-kW using software version 0024 or later and
by 5.5- and 7.5-kW Inverters using software version 0104 or later.
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
