Omron SYSDRIVE 3G3MV SERIES User Manual

5-31
Set Values
Value Function Description
0 Forward/Reverse rotation
command
3-wire sequence (to be set in n052 only)
By setting n052 to 0, the set values in n050 and n051 are ignored
and the following settings are forcibly made.
S1: RUN input (RUN when ON)
S2: STOP input (STOP when OFF)
S3: Forward/Reverse rotation command
(OFF: Forward; ON: Reverse)
1 Forward/Stop Forward rotation command in 2-wire sequence
2 Reverse/Stop Reverse rotation command (2-wire sequence)
3 External fault (NO)
ON: External fault (EFj detection: j is a terminal number)
4 External fault (NC)
OFF: External fault (EFj detection: j is a terminal number)
5 Fault reset ON: Fault reset (disabled while RUN command is input)
6 Multi-step speed
reference 1
Signals to select frequency references 2 through 16.
Note Refer to 5-6-4 Settin
g
the Fre
q
uenc
y
References throu
g
h Ke
y
7 Multi-step speed
reference 2
Note Refer to 5 6 4 Setting the Frequency References through Key
Sequences for the relationship between multi-step speed ref-
erences 1 throu
g
h 4 and fre
q
uenc
y
references 1 throu
g
h 16.
8 Multi-step speed
reference 3
erences 1 through 4 and frequency references 1 through 16
.
Note Any multi-step speed reference not set is regarded as turned-
OFF input.
9 Multi-step speed
reference 4
OFF input
.
10 Inching frequency
command
ON: Inching frequency command (taking precedence over the
multi-step speed reference)
11 Acceleration/deceleration
time selection 1
Refer to the description for set value 27.
12 External base block
command (NO)
ON: Output turned OFF (while motor coasting to a stop and “bb”
flashing)
13 External base block
command (NC)
OFF: Output turned OFF (with motor free running and “bb”
flashing)
14 Search command
(Searching starts from
maximum frequency)
ON: Speed search (Searching starts from n011)
15 Search command
(Searching starts from
preset frequency)
ON: Speed search
16 Acceleration/Decelera-
tion-prohibit command
ON: Acceleration/Deceleration is on hold (running at parameter
frequency)
17 Local or remote selection ON: Local mode (operated with the Digital Operator)
Note After this setting is made, mode selection with the Digital Oper-
ator is not possible.
18 Communications/Remote
selection
ON: RS-422/485 communications input is enabled.
Communications RUN command (0001 Hex) is enabled together
with frequency reference (0002 Hex).
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
