Omron SYSDRIVE 3G3MV SERIES - Removing the Bottom Cover

2-10
H Removing the Bottom Cover
D 0.2- to 3.7-kW Inverters
• After removing the front cover and terminal cover, press the bottom cover in the arrow 1 direction
based on position A as a fulcrum.
A
A
D 5.5-/7.5-kW Inverters
• After removing the terminal cover, loosen the fastening screws.
Design Chapter 2
