7-31
Series Communications
Board/Unit
Mounting method Specifications
SYSMAC CS CS1W-SCB41(-V1) As an Inner Board of the
CPU Unit
• One RS-232C port
• One RS-422/485 port
• Protocol macro function
SYSMAC CJ CJ1W-SCU41(-V1) CPU Bus Unit • One RS-232C port
• One RS-422/485 port
• Protocol macro function
SYSMAC
C200HX/HG/HE
C200HW-COM06-V1
Note Make sure that the
model number has
the suffix “V1,” as the
CRC-16 check code
is used.
Mounted to an optional slot
of the CPU Unit
• One RS-232C port
• One RS-422/485 port
• Protocol macro function
SYSMAC
CQM1H
CQM1H-SCB41
(Can be used with the
CQM1H-CPU61/51)
As an Inner Board of the
CPU Unit
• One RS-232C port
• One RS-422/485 port
• Protocol macro function
Note Refer to the SYSMAC CS/CJ Series Serial Communications Board/Unit Operation Manual (Cat.
No. W336) for information on RS-232C communications.
H Peripheral Devices
• The following peripheral devices are required to use the protocol macro function.
Name Model Specification
CX-Protocol WS02-PSTC1-E
The following peripheral devices support the protocol macro
function of the SYSMAC CS/CJ Series.
Personal computer environment
Personal
computer
IBM PC/AT or compatible computer
CPU Minimum requirement: Pentium 90 MHz
Recommended: Pentium 166 MHz or faster
OS Microsoft Windows 95, 98, Me, 2000, or XP
Memory Minimum: 16 MB
Recommended: 24 MB min.
Hard disk Minimum: Available space of 24 MB
Recommended: Available space of 50 MB
Monitor SVGA or better
Drive FDD: 1 or more
CD-ROM drive: 1 or more
