Omron SYSDRIVE 3G3MV SERIES User Manual

5-13
5-6-3 Frequency Referencing by Analog Input
This section explains the methods for referencing frequencies by analog input, adjusting
input characteristics, and detecting input command errors. Either the frequency refer-
ence control terminal (voltage/current) or multi-function analog voltage/current input
can be used for analog inputs. The gain, bias, and filter time parameters can be used for
adjustments, or, alternatively, the adjustments can be made by external analog voltage
(current), using the multi-function analog inputs.
H Setting Frequency References by Analog Input
• Analog inputs can be set only in remote mode. Set parameter n004 (frequency reference selection) to
any of the following: 2 to 4 (frequency reference control terminal), 7 (multi-function analog voltage in-
put), or 8 (multi-function analog current input).
Note If the frequency reference control terminal is to be used for current inputs, the SW2 setting must
be changed from V to I.
H FR Terminal Adjustments for Frequency Reference Input
D Gain and Bias Settings (n060 and n061)
• Set the input characteristics of analog frequency references in n060 (for the frequency reference gain)
and n061 (for the frequency reference bias).
• Set the frequency of maximum analog input (10 V or 20 mA) in n060 as percentage based on the maxi-
mum frequency as 100%.
Example: In order to obtain the maximum frequency at 5 V, set the value to 200% because 10-V
input is 200% maximum frequency.
• Set the frequency of minimum analog input (0 V, 0 mA, or 4 mA) in n061 as percentage based on the
maximum frequency as 100%.
Example: In order to obtain 50% maximum frequency output with 0 V input, set the value to 50%.
• Use the following equation to obtain the reference value for the analog input value.
Reference value = {Analog input (%)  (Gain – Bias)}  Maximum frequency + Bias  Maximum
frequency
n060
Frequency Reference Gain Register 013C Hex Changes during
operation
Yes
Setting
range
0% to 255%
(Max. frequency = 100%)
Unit of
setting
1% Default setting 100
n061
Frequency Reference Bias Register 013D Hex Changes during
operation
Yes
Setting
range
–99% to 99%
(Max. frequency = 100%)
Unit of
setting
1% Default setting 0
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
