5-14
D Filter Time Constant Settings (n062)
• A primary-delay digital filter can be set for analog frequency references to be input.
• This setting is ideal if the analog input signal changes rapidly or the signal is subject to noise interfer-
ence.
• The larger the set value is, the slower the response speed will be.
n062
Analog Frequency Reference
Filter Time Constant
Register 013E Hex Changes during
operation
No
Setting
range
0.00 to 2.00 (s) Unit of
setting
0.01 s Default setting 0.10
H Multi-function Analog Input
Various auxiliary analog inputs can be set for the Digital Operator’s multi-function analog voltage/cur-
rent input. Select from the following functions.
n077
Multi-function Analog Input
Terminal Function Selection
Register 014D Hex Changes during
operation
No
Setting
range
0 to 4 Unit of
setting
1 Default setting 0
n078
Multi-function Analog Input
Terminal Selection
Register 014E Hex Changes during
operation
No
Setting
range
0, 1 Unit of
setting
1 Default setting 0
n079
Multi-function Analog Input
Frequency Bias
Register 014F Hex Changes during
operation
No
Setting
range
0 to 50 Unit of
setting
1 % Default setting 10
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
