Omron SYSDRIVE 3G3MV SERIES User Manual

6-37
6-9 Slip Compensation Function
The slip compensation function calculates the motor torque according to the output cur-
rent, and sets gain to compensate for output frequency.
This function is used to improve speed accuracy when operating with a load. It is mainly
valid for V/f control.
Set the rated motor current (n036) and the motor no-load current (n110) before using the
slip compensation function. If n036 = 0, the slip compensation function cannot be used.
n106
Rated Motor Slip Register 016A Hex Changes during
operation
Yes
Setting
range
0.0 to 20.0 (Hz) Unit of
setting
0.1 Hz Default setting (See
note.)
Note The default setting varies with the capacity of the Inverter model.
Set Values
• Set the rated slip value of the motor in use.
• This parameter is used as a slip compensation constant.
• Calculate the rated motor slip value from the rated frequency (Hz) and rpm on the motor nameplate by
using the following formula.
Rated slit value (Hz) + Rated frequency (Hz) –
Rated rpm Number of poles
120
n111
Slip Compensation Gain Register 016F Hex Changes during
operation
Yes
Setting
range
0.0 to 2.5 Unit of
setting
0.1 Default setting 0.0
(See
note 1.)
Note 1. If set to vector control mode, the default value will be 1.0.
Note 2. This parameter is disabled with the value set to 0.0.
Set Values
• Set the parameter to 1.0 first and check the operation of the Inverter. Then fine-tune the gain with
0.1-gain increments or decrements.
If the speed is lower than the target value, increase the set value.
If the speed is higher than the target value, decrease the set value.
n112
Slip Compensation Primary Delay
Time
Register 0170 Hex Changes during
operation
No
Setting
range
0.0 to 25.5 (s) Unit of
setting
0.1 s Default setting 2.0 (See
note.)
Note If set to vector control mode, the default value will be 0.2.
Set Values
• This parameter is used for the response adjustment of the slip compensation function.
• The default setting does not need any changes in normal operation.
• Change the default setting in the following cases.
The motor vibrates: Set the value to a larger value.
The motor response is low: Set the value to a smaller value.
Advanced Operation Chapter 6

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
