5-11 Multi-function Analog Output and Pulse Monitor Output
The 3G3MV Inverter incorporates multi-function analog output terminals (AM and AC).
A parameter setting makes it possible to output pulse monitor signals from these termi-
nals. Make the necessary settings in these terminals according to the application.
5-11-1 Setting the Multi-function Analog Output (n065 through
n067)
• By setting n065 for multi-function analog output type selection to 0 for analog voltage output, analog
monitoring is possible through the multi-function analog output terminals.
• A monitoring item is set in n066 (multi-function analog output selection). Six items including the output
frequency and current are available.
• Set the analog output characteristics in n067 (multi-function analog output gain).
n065
Multi-function Analog Output Type
Selection
Register 0141 Hex Changes during
operation
No
Setting
range
0, 1 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 Analog voltage output (with monitoring item set in n066)
1 Pulse train output (according to output frequency set in n150)
n066
Multi-function Analog Output Register 0142 Hex Changes during
operation
No
Setting
range
0 to 5 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 Output frequency (Reference: 10-V output at max. frequency)
1 Output current (Reference: 10-V output at rated output current)
2 Main circuit DC voltage (Reference: 10-V output at 400 V DC for 200-V models and 800 V
DC for 400-V models)
3 Vector operation torque monitor (Reference: 10-V output at rated motor torque)
4 Output power (Reference: 10-V output at power equivalent to max. applicable motor capacity
and 0-V output during regenerative operation).
5 Output voltage (Reference: 10-V output at 200 V AC for 200-V models and 400 V AC for
400-V models)
Note Output power cannot be monitored in vector control mode.
n067
Multi-function Analog Output Gain Register 0143 Hex Changes during
operation
Yes
Setting
range
0.00 to 2.00 Unit of
setting
0.01 Default setting 1.00
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
