5-37
Value DescriptionFunction
8 Undertorque being
monitored (NO-contact
output)
Output if any of the following parameter conditions is satisfied.
• Undertorque detection function selection (n117)
• Undertorque detection level (n118)
O t d t ti f ti l ti 2 ( 097)
9 Undertorque being
monitored (NC-contact
output)
• Overtorque detection function selection 2 (n097)
• Undertorque detection time (n119)
Note NO contact: ON with undertorque being detected, NC contact:
OFF with undertorque being detected
10 Warning output ON: Warning being detected (Nonfatal error being detected)
11 Base block in progress ON: Base block in progress (in operation with output turned OFF)
12 RUN mode ON: Local mode (with the Digital Operator)
13 Inverter ready ON: Inverter ready to operate (with no fault detected)
14 Fault retry ON: Fault retry (Inverter resetting with fault retry (n082) not set to 0)
15 UV in progress ON: Undervoltage being monitored (main circuit undervoltage UV1
detected)
16 Rotating in reverse
direction
ON: Rotating in reverse direction
17 Speed search in progress ON: Speed search in progress
18 Communications output ON: Communications output (turns ON/OFF according to 0009 Hex
set from communications. Communications setting = ON)
19 PID feedback loss ON: PID feedback being lost (set detection method in n136, n137,
n138)
20 (See
note 2.)
Frequency reference loss ON: Frequency reference lost. (When the frequency reference loss
detection (n064) is enabled, and the frequency reference selection
(n004) is set for analog input or pulse train input.)
21 (See
note 2.)
Inverter overheating
warning oH3
ON: Inverter overheating warning
ON while the Inverter overheating warning signal is being input
(while oH3 is flashing).
Note 1. Use “during RUN” (set value: 1) or “zero speed“ (set value: 3) for the timing for stopping the
motor using a brake. To specify a precise stop timing, set “frequency detection 1” (set value: 4)
or “frequency detection 2” (set value: 5), and set the frequency detection level (n095).
Note 2. Set values 20 (frequency reference loss) and 21 (Inverter overheating warning oH3) are avail-
able for 5.5- and 7.5-kW Inverters only.
Basic Operation
Chapter 5
