6-14
6-3-4 Block Diagram of PID Control
The following diagram shows the PID control block of the 3G3MV Inverter.
Proportional (P) gain
Feedback value
adjustment gain
Limit
Integral time (I)
Derivative time (D)
0 (zero)
Multi-function input
Integral reset input
Integral (I) upper limit
0 (zero)
Derivative time (D)
Multi-function input
Integral hold input
Integral
hold
value
PID control selection
Limit
Max. frequency: 100%
PID primary
delay time
PID offset
adjustment
PID output gain
Limit
Max. frequency: 100%
Limit
Limit
Inverter output
frequency
Target
value
Feedback
value
Advanced Operation Chapter 6
