Page #112 background imageLoading...
Page #112 background image
5-10
5-5 Selecting the Operation Command
The following description provides information on how to input operation commands to
start or stop the Inverter or change the direction of rotation of the Inverter.
Two types of command input methods are available. Select either one of them according
to the application.
H Selecting the Operation Mode (n003)
Select the method of operation mode input to start or stop the Inverter.
The following method is enabled in remote mode only. The command can be input through key
sequences on the Digital Operator.
n003
Operation Command Selection Register 0103 Hex Changes during
operation
No
Setting
range
0 to 3 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 The RUN and STOP/RESET Keys of the Digital Operator are enabled.
1 Multi-function input in 2- or 3-wire sequence through the control circuit terminals is enabled.
2 RS-422/485 communications are enabled.
3 Input from option (DeviceNet Communications Unit) is enabled.
H Selecting the STOP/RESET Key Function (n007)
When parameter n003 is not set to 0, set whether or not to use the STOP/RESET Key of the Digital
Operator to stop the Inverter in remote mode. The STOP/RESET Key is always enabled in local mode
regardless of the setting in n007.
n007
STOP Key Function Selection Register 0107 Hex Changes during
operation
No
Setting
range
0, 1 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 The STOP/RESET Key of the Digital Operator is enabled.
1 The STOP/RESET Key of the Digital Operator is disabled.
Basic Operation
Chapter 5
