Omron SYSDRIVE 3G3MV SERIES User Manual

7-30
7-9 Communications with Programmable Controller
The Communications Board can be mounted to OMRON’s SYSMAC CS/CJ-series or
C200HX/HG/HE CPU Unit. The Inverter can then be controlled by the Communications
Board through its RS-422/485 port.
The communications protocol can be set by using the protocol macro function. There-
fore, there is no need to write a ladder program for the communications protocol when
the function is used.
The following description provides information on how to control the Inverter through
communications with the SYSMAC CS/CJ-series or C200HX/HG/HE Communications
Board by using the protocol macro function.
The RS-422/485 communications of the 3G3MV Inverter conform to the MODBUS
Communications Protocol and this protocol cannot be used together with DeviceNet
communications protocol or any other communications protocol. Only 3G3MV-series
Units can be connected as Slaves.
(The MODBUS Communications Protocol is a trademark of AEG Schneider Automa-
tion.)
7-9-1 Available Programmable Controllers and Peripheral
Devices
H OMRON’s SYSMAC CS/CJ-series or C200HX/HG/HE Programmable
Controller
• The following Communications Boards are needed to use the RS-422/485 communications port.
Note The RS-232C port can be used if an RS-422/485 conversion adapter is installed. For ease of wir-
ing, however, it is recommended that the RS-422/485 port be used. The following information is
for the RS-422/485 port.
Communications Chapter 7

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
