Omron SYSDRIVE 3G3MV SERIES User Manual

5-19
H Setting Frequency References 1 through 16 and the Inching Frequency
Command (n024 through n031, n120 through n127)
Frequency references 1 through 16 and an inching frequency command can be set together in the
Inverter (using registers n024 through n31, n120 through n127).
D Setting Frequency References 1 through 16 (n024 through n31, n120 through n127)
n024
Frequency Reference 1 Register 0118 Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 6.0
n025
Frequency Reference 2 Register 0119 Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n026
Frequency Reference 3 Register 011A Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n027
Frequency Reference 4 Register 011B Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n028
Frequency Reference 5 Register 011C Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n029
Frequency Reference 6 Register 011D Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n030
Frequency Reference 7 Register 011E Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n031
Frequency Reference 8 Register 011F Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
