Omron SYSDRIVE 3G3MV SERIES User Manual

5-20
n120
Frequency Reference 9 Register 0178 Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n121
Frequency Reference 10 Register 0179 Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n122
Frequency Reference 11 Register 017A Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n123
Frequency Reference 12 Register 017B Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n124
Frequency Reference 13 Register 017C Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n125
Frequency Reference 14 Register 017D Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n126
Frequency Reference 15 Register 017E Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
n127
Frequency Reference 16 Register 017F Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 0.00
Note 1. The setting unit of frequency references 1 through 16 is changed with the set value in n035 for
frequency reference setting and decimal place selection. Values will be set in 0.01-Hz incre-
ments if the frequency is less than 100 Hz and 0.1-Hz increments if the frequency is 100 Hz or
over.
Note 2. Frequency reference 1 is enabled with n004 for frequency reference selection set to 1.
Note 3. Frequency references 2 through 16 are enabled by setting multi-step speed references 1
through 4 in n050 through n056 for multi-function input. Refer to the following table for the
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
