relationship between multi-step speed references 1 through 4 and frequency references 1
through 16.
Frequency reference Multi-step speed
reference 1
(Set value: 6)
Multi-step speed
reference 2
(Set value: 7)
Multi-step speed
reference 3
(Set value: 8)
Multi-step speed
reference 4
(Set value: 9)
Frequency reference 1 OFF OFF OFF OFF
Frequency reference 2 ON OFF OFF OFF
Frequency reference 3 OFF ON OFF OFF
Frequency reference 4 ON ON OFF OFF
Frequency reference 5 OFF OFF ON OFF
Frequency reference 6 ON OFF ON OFF
Frequency reference 7 OFF ON ON OFF
Frequency reference 8 ON ON ON OFF
Frequency reference 9 OFF OFF OFF ON
Frequency reference 10 ON OFF OFF ON
Frequency reference 11 OFF ON OFF ON
Frequency reference 12 ON ON OFF ON
Frequency reference 13 OFF OFF ON ON
Frequency reference 14 ON OFF ON ON
Frequency reference 15 OFF ON ON ON
Frequency reference 16 ON ON ON ON
To change the frequency of frequency reference 2, for example, turn ON only the multi-function input
terminal where multi-step speed reference 2 is set, and turn OFF any other multi-function input terminal.
For example, no settings for multi-step speed reference 3 or 4 will be required if only frequency refer-
ences 1 through 4 are used. Any multi-step speed reference not set is regarded as turned-OFF input.
D Setting the Inching Frequency Command (n032)
• The inching frequency command must be set as multi-function input in order to use the inching fre-
quency command.
n032
Inching Frequency Command Register 0120 Hex Changes during
operation
Yes
Setting
range
0.00 to max. frequency Unit of
setting
0.01 Hz
(See note
1.)
Default setting 6.0
Note 1. The setting unit of the inching frequency command is changed with the set value in n035 for
frequency reference setting and decimal place selection. The value will be set in 0.01-Hz
increments if the frequency is less than 100 Hz and 0.1-Hz increments if the frequency is 100
Hz or over.
Note 2. In order to use the inching frequency command, one of the n050 through n056 parameters for
multi-function input must be set to 10 as an inching frequency command. Parameter n032 is
selectable by turning ON the multi-function input set with the inching frequency command.
The inching frequency command takes precedence over the multi-step speed reference (i.e.,
when the inching frequency command is ON, all multi-step speed reference input will be
ignored).
Basic Operation
Chapter 5

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
