Omron SYSDRIVE 3G3MV SERIES User Manual

6-18
Set Values
Value Description
0 Feedback loss detection disabled
1 Feedback loss detection enabled (Nonfatal error: FbL warning)
2 Feedback loss detection enabled (Fatal error: FbL error)
Note 1. Set the method of detecting loss of the feedback as a detected value for PID control.
Note 2. If the detection level set in n137 or lower is detected for the set time in n138, the result will be
determined as feedback loss.
n137
Feedback Loss Detection Level Register 0189 Hex Changes during
operation
No
Setting
range
0 to 100 (%) Unit of
setting
1% Default setting 0
n138
Feedback Loss Detection Time Register 018A Hex Changes during
operation
No
Setting
range
0.0 to 25.5 (s) Unit of
setting
0.1 s Default setting 1.0
Set Values
• These parameters are reference values for detecting loss of feedback for PID control.
• Set n137 to the feedback level in percentage based on the feedback level at maximum frequency as
100%.
• Set n138 in 0.1-s increments for the permissible continuous period of
the feedback signal level that is
the same as or less than the feedback level set in n137.
n163
PID Output Gain Register 01A3 Hex Changes during
operation
No
Setting
range
0.0 to 25.0 Unit of
setting
0.1 Default setting 1.0
Set Values
• Set this parameter to a rate by which PID control value is multiplied for PID control.
• Normally, the default setting does not need to be changed.
• This parameter is used for the adjustment of the PID control value to be added with the frequency
reference.
n164
PID Feedback Input Block
Selection
Register 01A4 Hex Changes during
operation
No
Setting
range
0 to 5 Unit of
setting
1 Default setting 0
Set Values
Value Description
0 Frequency reference control terminal for 0- to 10-V voltage input is enabled. (See note 1.)
1 Frequency reference control terminal for 4- to 20-mA current input is enabled. (See note 2.)
2 Frequency reference control terminal for 0- to 20-mA current input is enabled. (See note 2.)
3 Multi-function analog voltage (0- to 10-V) input is enabled.
Used only if two analog inputs are required in PID control.
4 Multi-function analog current (4- to 20-mA) input is enabled.
Used only if two analog inputs are required in PID control.
5 Pulse train reference control terminal is enabled. (See note 3.)
Advanced Operation Chapter 6

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
