7-15
H Example of Data Read
• In the following example, two-register data (the RUN command) is written from register 0002 Hex of
the Inverter with a Slave address of 01.
D DSR Message
Byte No. Data Data
example
(Hex)
1 Slave address 01
2 Function code 10
3
Register No. of write start data
00
4
g
01
5
Number of registers of write data
00
6
g
02
7 Data of start register 04
8
Data in register No. 0001
MSB 00
9
g
LSB 01
10
Data in register No. 0002
MSB 02
11
g
LSB 58
12
CRC-16 check
63
13 39
D Response
Normal
Byte No. Data Data
example
(Hex)
1 Slave address 01
2 Function code 10
3
Register No. of write start data
00
4
g
01
5
Number of registers of write data
00
6
g
02
7
CRC-16 check
10
8 08
Error
Byte No. Data Data
example
(Hex)
1 Slave address 01
2 Function code 90
3 Error code 02
4
CRC-16 check
DC
5 C1
Communications Chapter 7

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
