Omron SYSDRIVE 3G3MV SERIES User Manual

7-17
H Example of Loop-back Test
• In the following example, a loop-back test is conducted on the Inverter with a Slave address of 01.
D DSR Message
Byte No. Data Data
example
(Hex)
1 Slave address 01
2 Function code 08
3
Test data 1
00
4 00
5
Test data 2
A5
6 37
7
CRC-16 check
DA
8 8D
D Response
Normal
Byte No. Data Data
example
(Hex)
1 Slave address 01
2 Function code 08
3
Test data 1
00
4 00
5
Test data 2
A5
6 37
7
CRC-16 check
DA
8 8D
Error
Byte No. Data Data
example
(Hex)
1 Slave address 01
2 Function code 88
3 Error code 01
4
CRC-16 check
86
5 50
Communications Chapter 7

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
