Omron SYSDRIVE 3G3MV SERIES User Manual

9-4
Environ-
Location Indoors (with no corrosive gas, oil spray, or metallic dust)
ment
Ambient storage
temperature
–20 to 60°C
Ambient humidity Operating: 95% max. (with no condensation)
Ambient operating
temperature
Panel-mounting: –10 to 50°C Closed
wall-mounting:
–10 to 40°C
Panel-
mounting:
–10 to 50°C
Altitude 1,000 m max.
Insulation
resistance
5 MΩ min. (Do not carry out any insulation resistance or withstand
voltage tests)
Vibration resistance 9.8 m/s
2
max. between 10 to 20 Hz
2.0 m/s
2
max. between 20 and 50 Hz
Degree of protection Panel-mounting models: Conforms to IP20 Closed
wall-mounting
(NEMA1)/
Panel-
mounting
(IP00)
(See note 3.)
Note 1. The power supply capacity is the capacity for the Inverter’s rated output. It will vary depending
on the impedance at the input power supply. (This is due to fluctuations in the power factor.
The power factor can be improved by inserting an AC reactor.) There will also be variations in
the ratio between the rated current of the motor that is used and the rated output current of the
Inverter.
Note 2. The heat radiation is the electric power consumed in the Inverter at the Inverter’s rated output.
Note 3. The 5.5- and 7.5-kW Inverters are closed wall-mounting models (NEMA1/IP20) as a stan-
dard, but they can be converted to panel-mounting (IP00) by removing the top and bottom
covers.
Specifications
Chapter 9

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
