9-8
H Recommended Options
Name Model Description
AC Reactor (Yaskawa
Electric)
3G3IV-PUZBABj
Suppresses harmonic current generated from the
Inverter and improves the power factor of the Inverter.
Connect the AC Reactor to the Inverter if the capacity
of the power supply is much larger than that of the
Inverter.
EMC-conforming
Input Noise Filter
(Rasmi)
3G3IV-PRSj
A Noise Filter on the input side meeting the EC
Directive’s EMC requirements.
The top of the Noise Filter has mounting screw holes
with which the Inverter mounted to the Noise Filter
can be secured.
Simple Input Noise
Filter (Yaskawa
Electric)
3G3EV-PLNFDj
Each of these Filters connected to the power input
side eliminates noise in the power line connected to
the Inverter and suppresses noise leaking from the
Input Noise Filter
(Soshin Electric)
3G3IV-PFNj
pp g
Inverter to the power line.
Output Noise Filter
(Tokin)
3G3IV-PLFj
Connect this Filter to the output side of the Inverter to
suppress the noise generated by the Inverter from
being transmitted to the output line.
Specifications
Chapter 9

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
