H Applicable Models and Dimensions
D 200-V Class
Max. applicable
motor capacity (kW)
Model
3G3IV-PUZBABj
Current (A) Inductance
(mH)
Loss (W) Weight (kg)
0.1 to 0.2 2A7.0MH 2 7.0 8 2.5
0.4 2.5A4.2MH 2.5 4.2 15 2.5
0.75 5A2.1MH 5 2.1 15 2.5
1.5 10A1.1MH 10 1.1 25 3
2.2 15A0.71MH 15 0.71 30 3
3.7 20A0.53MH 20 0.53 35 3
5.5 30A0.35MH 30 0.35 45 3
7.5 40A0.265MH 40 0.265 50 4
Model
3G3IV PUZBABj
Dimension (mm)
3G3IV-PUZBABj
A B B1 C D E F H J K L M
2A7.0MH 120 71 --- 115 40 50 105 20 M6 10.5 7 M4
2.5A4.2MH 120 71 --- 120 40 50 105 20 M6 10.5 7 M4
5A2.1MH 120 71 --- 120 40 50 105 20 M6 10.5 7 M4
10A1.1MH 130 88 --- 130 50 65 130 22 M6 11.5 7 M4
15A0.71MH 130 88 --- 130 50 65 130 22 M6 11.5 7 M4
20A0.53MH 130 88 114 105 50 65 130 22 M6 11.5 7 M5
30A0.35MH 130 88 119 105 50 70 130 22 M6 9 7 M5
40A0.265MH 130 98 139 105 50 75 130 22 M6 11.5 7 M6
D 400-V Class
Max. applicable
motor capacity (kW)
Model
3G3IV-PUZBABj
Current (A) Inductance
(mH)
Loss (W) Weight (kg)
0.2 to 0.4 1.3A18.0MH 1.3 18.0 15 2.5
0.75 2.5A8.4MH 2.5 8.4 15 2.5
1.5 5A4.2MH 5 4.2 25 3
2.2 7.5A3.6MH 7.5 3.6 35 3
3.7 10A2.2MH 10 2.2 43 3
5.5 15A1.42MH 15 1.42 50 4
7.5 20A1.06MH 20 1.06 50 5
Specifications
Chapter 9

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
