Omron V1000 User Manual

i.1 Preface
OYMC distributes products used as components in a wide variety of industrial systems and equipment. The selection and
application of OYMC products remain the responsibility of the equipment manufacturer or end user. OYMC accepts no
responsibility for the way its products are incorporated into the final system design. Under no circumstances should any
OYMC product be incorporated into any product or design as the exclusive or sole safety control. Without exception, all
controls should be designed to detect faults dynamically and fail safely under all circumstances. All systems or equipment
designed to incorporate a product distributed by OYMC must be supplied to the end user with appropriate warnings and
instructions as to the safe use and operation of that part. Any warnings provided by OYMC must be promptly provided to
the end user. OYMC offers an express warranty only as to the quality of its products in conforming to standards and
specifications published in the OYMC manual. NO OTHER WARRANTY, EXPRESSED OR IMPLIED, IS OFFERED.
OYMC assumes no liability for any personal injury, property damage, losses, or claims arising from misapplication of its
products.
u
Applicable Documentation
The following manuals are available for V1000 series drives:
V1000 Series AC Drive Quick Start Guide
Read this manual first. This guide is packaged together with the product. It contains basic
information required to install and wire the drive. This guide provides basic programming and
simple setup and adjustment.
V1000 Series AC Drive User Manual
This manual describes installation, wiring, operation procedures, functions, troubleshooting,
maintenance, and inspections to perform before operation.
u
Symbols
Note: Indicates a supplement or precaution that does not cause drive damage.
TERMSTERMS
Indicates a term or definition used in this manual.
u
Terms and Abbreviations
TERMSTERMS
• Drive: OYMC V1000 Series Drive
• PM motor: Synchronous motor (an abbreviation for IPM motor or SPM motor)
• IPM motor: SSR1 Series
• OYMC: Omron Yaskawa Motion Control B.V.
i.1 Preface
12
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:22

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
