H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
H1: Multi-Function Digital Input
H1 parameters to assign functions to the multi-function digital input terminals. Unused terminals should be set to "F".
H1-01
Multi-Function Digital Input Terminal S1 Function
Selection
Assigns a function to the multi-
function digital inputs.
Refer to H1 Multi-Function Digital
Input Selections on page 315 for a
description of setting values.
1 to 9F
<40>
40 A A A 438 160
H1-02
Multi-Function Digital Input Terminal S2 Function
Selection
41 A A A 439 160
H1-03
Multi-Function Digital Input Terminal S3 Function
Selection
24 A A A 400 160
H1-04
Multi-Function Digital Input Terminal S4 Function
Selection
14 A A A 401 160
H1-05
Multi-Function Digital Input Terminal S5 Function
Selection
3 (0)
<18>
A A A 402 160
H1-06
Multi-Function Digital Input Terminal S6 Function
Selection
4 (3)
<18>
A A A 403 160
<18> Parenthetical value is the default when parameter A1-03 = 3330 3-Wire Initialization.
<40> The availability of certain functions depends on the control method used.
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description
Control
Mode
Pg.
V/f
OL
V
PM
0 3-Wire Sequence Closed: Reverse rotation (only if the drive is set up for 3-Wire sequence) O O O 160
1 LOCAL/REMOTE Selection
Open: REMOTE, Reference 1 or 2 (b1-01/02 or b1-15/16)
Closed: LOCAL, LED operator is run and reference source
O O O 161
2 External Reference 1/2
Open: Run and frequency reference source 1 (b1-01/02)
Closed: Run and frequency reference source 2 (b1-15/16)
O O O 161
3 Multi-Step Speed Reference 1
Used to select Multi-Step Speeds set in d1-01 to d1-16
O O O 161
4 Multi-Step Speed Reference 2 O O O 161
5 Multi-Step Speed Reference 3 O O O 161
6 Jog Reference Selection
Open: Selected speed reference
Closed: Jog Frequency reference (d1-17). Jog has priority over all other
reference sources.
O O O 161
7 Accel/Decel Time 1 Used to switch between Accel/Decel. Time 1/2 O O O 161
8 Baseblock Command (N.O.)
Open: Normal operation
Closed: No drive output
O O O 162
9 Baseblock Command (N.C.)
Open: No drive output
Closed: Normal operation
O O O 162
A Accel/Decel Ramp Hold
Closed: The drive pauses during acceleration or deceleration and
maintains the output frequency.
O O O 162
B Drive Overheat Alarm (oH2) Closed: Displays an oH2 alarm O O O 162
C Terminal A1/A2 Enable
Open: Terminal A1/A2 disabled
Closed: Terminal A1/A2 enabled
O O O 162
F Not used
Select this setting when not using the terminal or when using the terminal
in a pass-through mode.
O O O 162
10 Up Command Open: Maintains the current frequency reference
Closed: Increases or decreases the current frequency reference.
Ensure that the increase and decrease commands are set in conjunction
with one another.
O O O 162
11 Down Command O O O 162
12 Forward Jog Closed: Runs forward at the Jog Frequency d1-17. O O O 163
13 Reverse Jog Closed: Runs reverse at the Jog Frequency d1-17. O O O 163
14 Fault Reset
Closed: Resets faults if the cause is cleared and the Run command is
removed.
O O O 164
15 Fast-Stop (N.O.)
Closed: Decelerates at the Fast-Stop time C1-09.
To restart the Fast-Stop input must be released and Run must be cycled.
O O O 164
16 Motor 2 Selection
Open: Motor 1 (E1-, E2-)
Closed: Motor 2 (E3-, E4-)
O O O 164
17 Fast-stop (N.C.) Open: Decelerates according to C1-09 (Fast-stop Time) O O O 164
18 Timer Function Input
Set the timer delay using parameters b4-01 and b4-02.
Ensure this function is set in conjunction with the multi-function output
timer (H2- = 12).
O O O 165
19 PID Disable Closed: PID control disabled O O O 165
1A Accel/Decel Time Selection 2 Switches Accel/Decel times. O O O 165
B.2 Parameter Table
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
315
