Omron V1000 User Manual

Electrical Installation
This chapter explains proper procedures for wiring the control circuit terminals, motor and power
supply.
3.1 SECTION SAFETY............................................................................................38
3.2 STANDARD CONNECTION DIAGRAM...........................................................40
3.3 MAIN CIRCUIT CONNECTION DIAGRAM.......................................................42
3.4 TERMINAL BLOCK CONFIGURATION...........................................................43
3.5 PROTECTIVE COVERS....................................................................................44
3.6 MAIN CIRCUIT WIRING....................................................................................46
3.7 CONTROL CIRCUIT WIRING...........................................................................50
3.8 I/O CONNECTIONS...........................................................................................55
3.9 MAIN FREQUENCY REFERENCE...................................................................57
3.10 MEMOBUS/MODBUS TERMINATION.............................................................58
3.11 BRAKING RESISTOR.......................................................................................59
3.12 WIRING CHECKLIST........................................................................................61
3
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
37
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
