Omron V1000 User Manual

MEMOBUS/Modbus Communications
C.1 SECTION SAFETY..........................................................................................352
C.2 MEMOBUS/MODBUS CONFIGURATION......................................................353
C.3 COMMUNICATION SPECIFICATIONS..........................................................354
C.4 CONNECTING TO A NETWORK....................................................................355
C.5 MEMOBUS/MODBUS SETUP PARAMETERS..............................................358
C.6 DRIVE OPERATIONS BY MEMOBUS/MODBUS..........................................361
C.7 COMMUNICATIONS TIMING..........................................................................362
C.8 MESSAGE FORMAT.......................................................................................363
C.9 MESSAGE EXAMPLES..................................................................................365
C.10 MEMOBUS/MODBUS DATA TABLE.............................................................367
C.11 ENTER COMMAND.........................................................................................375
C.12 COMMUNICATION ERRORS.........................................................................376
C.13 SELF-DIAGNOSTICS......................................................................................377
Appendix: C
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
351
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
