SS5 Motor: Yaskawa SSR1 Series IPM Motor
Table B.10 200 V, 1750 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1202 1203 1205 1206 1208
Voltage class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW
Rated speed r/min 1750 1750 1750 1750 1750
E5-02 Motor rated power kW 0.4 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 1.65 2.97 5.50 8.10 13.40
E5-04 Motor pole number – 6 6 6 6 6
E5-05 Motor winding resistance W 8.233 2.284 1.501 0.827 0.455
E5-06 d-axis inductance mH 54.84 23.02 17.08 8.61 7.20
E5-07 q-axis inductance mH 64.10 29.89 21.39 13.50 10.02
E5-09 Induction voltage constant 1 mVs/rad 233.0 229.5 250.9 247.9 248.6
E5-24 Induction voltage constant 2 mV/(r/min) 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 190.0 190.0 190.0 190.0 190.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum output frequency Hz 4.4 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.092 0.076 0.051 0.066 0.075
n8-49 Pull-in current % –7.2 –10.8 –11.1 –17.8 –17.5
Par. Description Unit Default Settings
E5-01
Motor Code − 120A 120B 120D 120E
Voltage class − 200 Vac 200 Vac 200 Vac 200 Vac
Rated power − 5.5 kW 7.5 kW 11 kW 15 kW
Rated speed r/min 1750 1750 1750 1750
E5-02 Motor rated power kW 5.5 7.5 11.0 15
E5-03 Motor rated current A 19.80 27.00 39.7 53.2
E5-04 Motor pole number – 6 6 6 6
E5-05 Motor winding resistance W 0.246 0.198 0.094 0.066
E5-06 d-axis inductance mH 4.86 4.15 3.40 2.65
E5-07 q-axis inductance mH 7.43 5.91 3.91 3.11
E5-09 Induction voltage constant 1 mVs/rad 249.6 269.0 249.3 266.6
E5-24 Induction voltage constant 2 mV/(r/min) 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 190.0 190.0 190.0 190.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5
E1-09 Minimum output frequency Hz 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.083 0.077 0.084 0.102
n8-49 Pull-in current % –22.0 –17.3 –10.1 –10.3
B.6 Parameters that Change with the Motor Code Selection
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
349
B
Parameter List
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
