1.3 Drive Models and Enclosure Types

The following table describes drive enclosures and models.

Table 1.1 Drive Models and Enclosure Types

Voltage Class

Enclosure Type

IP20/Open-Chassis

VZA

IP20/NEMA Type 1

VZA

Single-Phase

200 V Class

B0P1B —

B0P2B —

B0P4B —

B0P7B —

B1P1B —

B2P2B —

B4P0B —

Three-Phase

200 V Class

20P1B —

20P2B —

20P4B —

20P7B —

21P5B —

22P2B —

24P0B —

— 25P5F

— 27P5F

— 2011F

— 2015F

Three-Phase

400 V Class

40P2B —

40P4B —

40P7B —

41P5B —

42P2B —

43P0B —

44P0B —

— 45P5B

— 47P5B

— 4011B

— 4015B

Two types of enclosures are offered for V1000 drives.

• IP20/Open-Chassis models are often placed inside a large enclosure panel where the front of the drive is covered to

prevent someone from accidentally touching charged components.

• IP20/NEMA Type 1 models mount to an indoor wall and not inside a large enclosure panel.

1.3 Drive Models and Enclosure Types

SIEP C710606 20 OYMC AC Drive - V1000 User Manual

Receiving

7/16/2008-13:22
