B.6 Parameters that Change with the Motor Code Selection
The following tables show parameters and default settings that change with the motor code selection E5-01 when Open
Loop Vector for PM motors is used.
u
Yaskawa SMRA Series SPM Motor
Table B.8 1800 rpm Type Yaskawa SMRA Series SPM Motor Settings
Par. Description Unit Default Settings
E5-01
Motor Code − 0002 0003 0005 0006 0008
Voltage class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW
Rated speed r/min 1800 1800 1800 1800 1800
E5-02 Motor rated power kW 0.4 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 2.1 4.0 6.9 10.8 17.4
E5-04 Motor pole number – 8 8 8 8 8
E5-05 Motor winding resistance W 2.47 1.02 0.679 0.291 0.169
E5-06 d-axis inductance mH 12.7 4.8 3.9 3.6 2.5
E5-07 q-axis inductance mH 12.7 4.8 3.9 3.6 2.5
E5-09 Induction voltage constant 1 mVs/rad 0 0 0 0 0
E5-24 Induction voltage constant 2 mV/(r/min) 62.0 64.1 73.4 69.6 72.2
E1-04 Maximum output frequency Hz 120 120 120 120 120
E1-05 Maximum output voltage V 200.0 200.0 200.0 200.0 200.0
E1-06 Base voltage Hz 120 120 120 120 120
E1-09 Minimum output frequency Hz 6 6 6 6 6
L3-24 Motor acceleration time s 0.064 0.066 0.049 0.051 0.044
n8-49 Pull-in current % 0 0 0 0 0
Table B.9 3600 rpm Type Yaskawa SMRA Series SPM Motor Settings
Par. Description Unit Default Settings
E5-01
Motor Code − 0103 0105 0106 0108
Voltage class − 200 Vac 200 Vac 200 Vac 200 Vac
Rated power − 0.75 kW 1.5 kW 2.2 kW 3.7 kW
Rated speed r/min 3600 3600 3600 3600
E5-02 Motor rated power kW 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 4.1 8.0 10.5 16.5
E5-04 Motor pole number – 8 8 8 8
E5-05 Motor winding resistance W 0.538 0.20 0.15 0.097
E5-06 d-axis inductance mH 3.2 1.3 1.1 1.1
E5-07 q-axis inductance mH 3.2 1.3 1.1 1.1
E5-09 Induction voltage constant 1 mVs/rad 0 0 0 0
E5-24 Induction voltage constant 2 mV/(r/min) 32.4 32.7 36.7 39.7
E1-04 Maximum output frequency Hz 240 240 240 240
E1-05 Maximum output voltage V 200.0 200.0 200.0 200.0
E1-06 Base voltage Hz 240 240 240 240
E1-09 Minimum output frequency Hz 12 12 12 12
L3-24 Motor acceleration time s 0.064 0.066 0.049 0.051
n8-49 Pull-in current % 0 0 0 0
