A.2 Single/Three-Phase 200 V Class Drive
Table A.2 Power Ratings
Item Specification
Three-Phase: VZA 20P1 20P2 20P4 20P7 21P5 22P2 24P0
Single-Phase: VZA
<1>
B0P1 B0P2 B0P4 B0P7 B1P5 B2P2
B4P0
<2>
Maximum Motor Size Allowed (kW)
<3>
HD Rating 0.1 0.2 0.4 0.75 1.5 2.2 4.0
ND Rating 0.2 0.4 0.75 1.1 2.2 3.0
5.5
<2>
Input
Input Current (A)
<4>
Three-Phase
HD Rating 0.7 1.5 2.9 5.8 7.5 11.0 18.9
ND Rating 1.1 1.9 3.9 7.3 10.8 13.9 24.0
Single-Phase
HD Rating 1.4 2.8 5.5 11.0 14.1 20.6 35.0
ND Rating 2.0 3.6 7.3 13.8 20.2 24.0 –
Output
Rated Output Capacity (kVA)
<5>
HD Rating 0.3 0.6 1.1 1.9 3.0 4.2 6.7
ND Rating 0.5 0.7 1.3 2.3 3.7 4.6 7.5
Output Current (A)
HD Rating
0.8
<7>
1.6
<7>
3.0
<7>
5.0
<7>
8.0
<8>
11.0
<8>
17.5
<8>
ND Rating
<6>
1.2 1.9 3.5 (3.3) 6.0 9.6 12.0 19.6
Overload Tolerance
ND Rating: 120% of rated output current for 1 minute
HD Rating: 150% of rated output current for 1 minute
(Derating may be required for applications that start and stop frequently)
Carrier Frequency
User adjustable between 2 and 15 kHz (see HD output current line of this
table for default values)
Max Output Voltage (V) Three-phase 200 to 240 V (proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: Three-phase 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective Actions DC Reactor Optional
<1> Drives with single-phase power supply input will output three-phase power and cannot run a single-phase motor.
<2> This drive does not have a Normal Duty rating.
<3> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<4> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.
<5> Rated motor capacity is calculated with a rated output voltage of 220 V.
<6> Carrier frequency is set to Swing PWM. Current derating is required in order to raise the carrier frequency.
<7> Carrier frequency is set to 10 kHz. Current derating is required in order to raise the carrier frequency.
<8> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
A.2 Single/Three-Phase 200 V Class Drive
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
289
A
Specifications
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
