B.3 Control Mode Dependent Parameter Default Values
The tables below list parameters that depend on the control mode selection (A1-02 for motor 1, E3-01 for motor 2). These
parameters are initialized to the shown values if the control mode is changed.
Table B.1 A1-02 (Motor 1 Control Mode) Dependent Parameters and Default Values
Parameter Description Setting Range Resolution
Control Modes (A1-02)
V/f (0) OLV (2) PM (5)
b3-02 Speed Search deactivation current 0 to 200 1% 120 100
b8-02 Energy Saving gain 0.0 to 10.0 0.1 0.7
C2-01 S-curve time at acceleration start 0.00 to 10.00 0.01 s 0.20 0.20 1.00
C3-01 Slip compensation gain 0.0 to 2.5 0.1 0.0 1.0
C3-02 Slip compensation time constant 0 to 10000 1 ms 2000 200
C4-01 Torque compensation gain 0.00 to 2.50 0.01 1.00 1.00 0.00
C4-02 Torque comp. primary delay time 0 to 10000 1 ms 200 20 100
C6-02 Carrier frequency 1 to F 1
<12> <12>
2
E1-04 Maximum output frequency 40.0 to 400.0 0.1 Hz 50.0 50.0
<10>
E1-05
Maximum output voltage
<24>
0.0 to 255.0 0.1 V 200.0 200.0
<10>
E1-07 Middle output frequency 0.0 to 400.0 0.1 Hz 2.5 3.0
E1-09 Minimum output frequency 0.0 to 400.0 0.1 Hz 1.3 0.5
<10>
E1-10
Minimum output voltage
<24>
0.0 to 255.0 0.1 V 12.0 3.0
E1-11 Middle output frequency 2 0.0 to 400.0 0.1 Hz 0.0 0.0
E1-12
Middle output freq. voltage 2
<24>
0.0 to 255.0 0.1 V 0.0 0.0
E1-13
Base voltage
<24>
0.0 to 255.0 0.1 V 0.0 0.0
L1-01 Motor protection selection 0 to 4 - 1 1 4
L3-20 Accel/Decel rate calculation rate 0.00 to 5.00 0.01 1.00 0.30 0.65
L3-21
Decel time at Stall Prevention during
acceleration
0.00 to 200.00 0.01 1.00 1.00 2.50
<10> Default setting value is dependent on parameter E5-01, Motor Code Selection.
<12> Default setting value is dependent on parameter o2-04, Drive Model Selection.
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
Table B.2 E3-01 (Motor 2 Control Mode) Dependent Parameters and Default Values
Parameter Description Setting Range Resolution
Control Modes (E3-01)
V/f (0) OLV (2)
E3-04 Maximum output frequency 40.0 to 400.0 0.1 Hz 50.0 50.0
E3-05
Maximum output voltage
<24>
0.0 to 255.0 0.1 V 200.0 200.0
E3-06 Base Frequency 0.0 to 400.0 0.1 Hz 50.0 50.0
E3-07 Middle output frequency 0.0 to 400.0 0.1 Hz 2.5 3.0
E3-08
Middle output freq. voltage
<24>
0.0 to 255.0 0.1 V 16.0 14.4
E3-09 Minimum output frequency 0.0 to 400.0 0.1 Hz 1.3 0.5
E3-11 Middle output frequency 2 0.0 to 400.0 0.1 Hz 0.0 0.0
E3-12
Middle output freq. voltage 2
<24>
0.0 to 255.0 0.1 V 0.0 0.0
E3-13
Base voltage
<24>
0.0 to 255.0 0.1 V 0.0 0.0
E3-14 Motor 2 Slip compensation gain 0.0 to 2.5 0.1 0.0 1.0
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
B.3
Control Mode Dependent Parameter Default Values
338
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23
