A.4 Drive Specifications
Note: Perform rotational Auto-Tuning to obtain OLV performance specifications.
Note: For optimum performance life of the drive, install the drive in an environment that meets the environmental conditions.
Item Specification
Control
Characteristics
Control Method
The following control methods are available:
Open Loop Vector Control (current vector), V/f Control, and PM Open Loop Vector for
(for use with SPM and IPM)
Frequency Control Range 0.01 to 400 Hz
Frequency Accuracy
Digital input: within ±0.01% of the max output frequency (-10 to +50 °C)
Analog input: within ±0.5% of the max output frequency (25 °C ±10 °C)
Frequency Setting Resolution
Digital inputs: 0.01 Hz
Analog inputs: 1/1000 of maximum output frequency
Output Frequency Calculation
Resolution
1/2
20
x Maximum output frequency (E1–04)
Frequency Setting Signal
Main frequency reference: 0 to +10 Vdc (20 kΩ), 4 to 20 mA (250 Ω), 0 to 20 mA
(250 Ω)
Main speed reference: Pulse Train Input (max 32 kHz)
Starting Torque
200%/0.5 Hz (Open Loop Vector Control, HD rating, IM of 3.7 kW or smaller), 50%/6
Hz (PM Open Loop Vector Control)
Speed Control Range
1:100 (Open Loop Vector Control), 1:40 (V/f Control), 1:10 (PM Open Loop Vector
Control)
Speed Control Accuracy
±0.2% in Open Loop Vector Control
<1>
Speed Response
5 Hz (25 °C ±10 °C) in Open Loop Vector Control
(excludes temperature fluctuation when performing Rotational Auto-Tuning)
Torque Limit Open Loop Vector Control only. Adjustable in 4 quadrants.
Accel/Decel Time 0.00 to 6000.0 s (allows four separate settings for accel and decel)
Braking Torque
Instantaneous Average Decel Torque
<2>
: 0.1/0.2 kW: over 150%, 0.4/0.75 kW: over
100%, 1.5 kW: over 50%, 2.2 kW and above: over 20%
Continuous Regen Torque: 20%,
125% with a Braking Resistor Unit
<3>
: (10% ED) 10 s with an internal braking resistor.
V/f Characteristics Preset V/f patterns and user-set program available.
Functions
Momentary Power Loss Ride-Thru
Speed Search
Over/Undertorque Detection
Torque Limit, Multi-Step Speed (17 steps max)
Accel/Decel Time Switch
S-Curve Accel/Decel,
3-Wire Sequence
Rotational Auto-Tuning
Stationary Auto-Tuning of Line-to-Line Resistance
Dwell
Cooling Fan ON/OFF
Slip Compensation
Torque Compensation
Jump Frequencies (reference dead band)
Frequency Reference Upper/Lower Limit
DC Injection Braking (start and stop), High Slip Braking
PID Control (with Slip Function)
Energy Saving
MEMOBUS/Modbus (RS-485/422 Max 115.2 kbps)
Fault Reset
Parameter Copy
Protection
Functions
Motor Protection Motor overheat protection via output current sensor
Overcurrent Protection Drives stops when output exceeds 200% of the rated current (Heavy Duty)
Overload Protection
A stop command will be entered after operating at 150% for 60 s (Heavy Duty)
<4>
Low Voltage Protection
Drive stops when DC bus voltage falls below the levels indicated:
<5>
190 V (3-phase 200 V), 160 V (single-phase 200 V), 380 V (3-phase 400 V), 350 V (3-
phase 380 V)
Momentary Power Loss Ride-Thru
3 selections available: Ride-Thru disabled (stops after 15 ms), time base of 0.5 s, and
continue running as long as the drive control board is powered up.
<6>
Heatsink Overheat Protection Protected by thermistor
Braking Resistor Overheat Protection Overheat input signal for braking resistor (Optional ERF-type, 3% ED)
Stall Prevention
Stall prevention is available during acceleration, deceleration, and during run. Separate
settings for each type of stall prevention determine the current level at which stall
prevention is triggered.
Cooling Fan Failure Protection Circuit protection (“fan-lock” sensor)
Ground Protection
Electronic circuit protection
<7>
DC Bus Charge LED Remains lit until DC bus voltage falls below 50 V
