No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
r1-39
FBDs Connection Parameter
20 (upper)
Parameter 20 for connecting FBDs (upper).
0 to
FFFFH
0 – A A 1866 —
r1-40
FBDs Connection Parameter
20 (lower)
Parameter 20 for connecting FBDs (lower).
0 to
FFFFH
0 – A A 1867 —
u
T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
T1-00 Motor Selection 1/2
Selects which set of motor parameters are used and set during
Auto-Tuning. If Motor 2 selection (H1- = 16) is not selected,
this parameter will not be displayed.
1: 1st Motor - E1 to E2
2: 2nd Motor - E3 to E4 (this selection is not displayed if motor 2
has not been selected)
2: 2nd Motor - E3 to E4
1, 2 1 A A − 700 90
T1-01
Auto-Tuning Mode
Selection
Selects the Auto-Tuning mode.
0: Rotational Auto-Tuning
2: Stationary Auto-Tuning for Line-to-Line Resistance
3: Rotational Auto-Tuning for V/f Control (necessary for Energy
Savings and Speed Estimation type Speed Search)
0, 2, 3
<54>
2 or 3 in
V/f
0 or 2 in
OLV
2 in
Motor 2
A A − 701 90
T1-02 Motor Rated Power
Sets the motor rated power in kilowatts (kW).
Note: If motor power is given in horsepower, power in kW can be
calculated using the following formula: kW = HP x 0.746.
0.00 to
650.00
<12>
A A − 702 90
T1-03
<24>
Motor Rated
Voltage
Sets the motor rated voltage in volts (V).
0.0 to
255.5
200.0 V A A − 703 90
T1-04 Motor Rated Current Sets the motor rated current in amperes (A).
10 to 200%
of drive
rated
current
<12>
A A − 704 91
T1-05
Motor Base
Frequency
Sets the base frequency of the motor in Hertz (Hz).
0.0 to
400.0
60.0 Hz A A − 705 91
T1-06
Number of Motor
Poles
Sets the number of motor poles. 2 to 48 4 A A − 706 91
T1-07 Motor Base Speed
Sets the base speed of the motor in revolutions per minute r/min
(RPM).
0 to 24000
1750 r/
min
A A − 707 91
T1-11 Motor Iron Loss
Provides the iron loss for determining the Energy Saving
coefficient.
The value set to E2-10 (motor iron loss) when the power is cycled.
If T1-02 is changed, an initial value valid for the selected capacity
will be shown.
0 to 65535
14 W A − − 70B 91
These values differ depending on the
motor code value and motor
parameter settings.
<12> Default setting value is dependent on parameter o2-04, Drive Model Selection.
<24> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<54> The available tuning methods depend on control mode. Select values 2 or 3 in V/f Control, 0 or 2 in OLV control, and 2 for Motor 2 control.
u
U: Monitors
Monitor parameters allow the user to view drive status, fault information, and other information about drive operation.
No. Name Description
Analog Output
Level
Unit
Control
Mode
Addr.
Hex
V/f
O
LV
P
M
U1: Operation Status Monitors
Use U1 monitors to display the operation status of the drive.
U1-01 Frequency Reference Monitors the frequency
10 V: Max
frequency
0.01
Hz
A A A 40
U1-02 Output Frequency
Displays the output frequency. Display units are
determined by o1-03.
10 V: Max
frequency
0.01
Hz
<27>
A A A 41
U1-03 Output Current Displays the output current.
10 V: Drive rated
current
0.01A A A A 42
B.2 Parameter Table
332
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23
