Omron V1000 User Manual

A.5 Drive Watt Loss Data
Table A.6 Watt Loss 200 V Class Single-Phase Models
Model Number
VZA
Heavy Duty (Carrier Frequency 8 kHz)
<1>
Normal Duty (Swing PWM equal 3 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
B0P1 0.8 4.3 7.4 11.7 1.2 5.0 8.5 13.5
B0P2 1.6 7.9 8.9 16.7 1.9 7.6 9.7 17.3
B0P4 3.0 16.1 11.5 27.7 3.2 14.6 14.4 29.1
B0P7 5.0 33.7 16.8 50.5 6.0 30.1 19.4 49.5
B1P1 8.0 54.8 25.9 80.7 9.6 51.7 29.8 81.4
B2P2 11.0 70.7 34.1 104.8 12.0 61.3 37.1 98.4
B4P0 17.5 110.5 51.4 161.9 — — — —
<1> 10 kHz for B0P1 to B0P7
Table A.7 Watt Loss 200 V Class Three-Phase Models
Model Number
VZA
Heavy Duty (Carrier Frequency 8 kHz)
<1>
Normal Duty (Swing PWM equal 3 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
20P1 0.8 4.3 7.3 11.6 1.2 5.0 8.0 13.0
20P2 1.6 7.9 8.8 16.7 1.9 7.6 9.5 17.1
20P4 3.0 16.2 11.5 27.7 3.5 15.8 13.6 29.4
20P7 5.0 27.4 15.9 43.3 6.0 27.5 17.2 44.7
21P5 8.0 54.8 23.8 78.6 9.6 51.7 25.8 77.5
22P2 11.0 70.7 29.9 100.6 12.0 61.3 30.4 91.7
24P0 17.5 110.5 43.3 153.8 19.6 98.7 46.3 145.0
25P5 25.0 231.5 72.2 303.7 30.0 246.4 88.9 335.3
27P5 33.0 339.5 82.8 321.3 40.0 266.7 112.8 379.6
2011 47.0 347.6 117.6 465.2 56.0 357.9 151.8 509.7
2015 60.0 437.7 151.4 589.1 69.0 461.7 184.5 646.2
<1> 10 kHz for 20P1 to 20P7
Table A.8 Watt Loss 400 V Class Three-Phase Models
Model Number
VZA
Heavy Duty (Carrier Frequency 8 kHz) Normal Duty (Swing PWM equal 3 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
40P2 1.2 19.2 11.5 30.7 1.2 10.0 9.6 19.6
40P4 1.8 28.9 14.8 43.7 2.1 18.5 13.9 32.4
40P7 3.4 42.3 17.9 60.2 4.1 30.5 16.8 47.3
41P5 4.8 70.7 26.2 96.9 5.4 44.5 21.8 66.3
42P2 5.5 81.0 30.7 111.7 6.9 58.5 28.4 86.9
43P0 7.2 84.6 32.9 117.5 8.8 63.7 31.4 95.1
44P0 9.2 107.2 41.5 148.7 11.1 81.7 46.0 127.7
45P5 14.8 166.0 62.7 228.7 17.5 181.2 80.1 261.3
47P5 18.0 207.1 78.1 285.2 23.0 213.4 107.7 321.1
4011 24.0 266.9 105.9 372.8 31.0 287.5 146.1 433.6
4015 31.0 319.1 126.6 445.7 38.0 319.2 155.8 475.0
A.5 Drive Watt Loss Data
294
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
