Subchart A1: Simple Motor Setup with Energy Savings or Speed Search Using V/f
Mode
Figure 4.7, Flowchart A1, describes simple motor setup for V/f control. V/f Motor Control is suited for the most basic
applications such as fans or pumps. This procedure illustrates using Energy Savings and Speed Estimation Speed Search.
V/f control can be used where rotational auto-tuning cannot be performed.
From
Flowchart
A
Set or verify the V/f pattern settings E1-.
Energy Savings
(b8-01=1)
or
Speed Estimation
Speed Search (b3-24=1)
enabled ?
Is the motor cable
longer than 50 m?
Perform Rotational Auto-Tuning
for V/f Control
(T1-01 = 3)
NO
YES
Perform Stationary Auto-Tuning for
terminal resistance (T1-01 = 2)
YES
NO
Return to
Flowchart
A
Figure 4.7 Simple Motor Set-Up with Energy Savings or Speed Search Using V/f Mode
4.4 Start-up Flowcharts
78
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
