n
E4-14: Motor 2 Slip Compensation Gain
Instead of C3-01 the value of E4-14 is used as gain for slip compensation when motor 2 is selected. Refer to C3-01: Slip
Compensation Gain on page 127 for details and setting instructions.
No. Parameter Name Setting Range Default
E4-14 Motor 2 Slip Compensation Gain 0.0 to 2.50
Depending on
E3-01
n
E4-15: Motor 2 Torque Compensation Gain
Instead of C4-01 the value of E4-15 is used as gain for torque compensation when motor 2 is selected. Refer to C4-01:
Torque Compensation Gain on page 128 for details and setting instructions.
No. Parameter Name Setting Range Default
E4-15 Motor 2 Torque Compensation Gain 0.0 to 2.50 1.00
u
E5: PM Motor Settings
These parameters set the motor data of a PM motor used in OLV for PM (A1-02 = 5).
When Yaskawa motors are used, entering the motor code written on the motor nameplate will set up the E5- parameters.
For all other PM motors, the data must be entered manually.
n
E5-01: PM Motor Code Selection
Set the motor code for the PM motor being used. Depending on the motor code entered, the drive automatically sets several
parameters to appropriate values. Refer to Parameters that Change with the Motor Code Selection on page 348 for
details on the supported motor codes and their parameter settings.
No. Parameter Name Setting Range Default
E5-01 PM Motor Code Selection 0000 to FFFF
Depending on
o2-04
Note: 1. This parameter is not reset when the drive is initialized using parameter A1-03.
2. The default setting is for a Yaskawa SMRA Series SPM Motor with a speed rating of 1800 r/min.
3.
Changing the motor code setting resets all E5- settings to their default values.
4. Set to “FFFF” when using a non-Yaskawa PM motor or one that is not supported by the motor code settings.
Figure 5.42 explains the motor code setting.
0 0 0 0
0: 1800 r/min Series
1: 3600 r/min Series
2: 1750 r/min Series
3: 1450 r/min Series
4: 1150 r/min Series
F: Special Motor
Motor Voltage Class
and Capacity
0: Pico Motor
(SMRA Series)
1: Derated Torque for IPM
Motors
(SSR 1 Series)
Figure 5.42
PM Motor Code
n
E5-02: Motor Rated Power (PM OLV)
Sets the rated power of the motor.
No. Parameter Name Setting Range Default
E5-02 Motor Rated Power 0.10 to 18.50 kW
Depending on
E5-01
Note: This parameter is not reset when the drive is initialized using A1-03.
n
E5-03: Motor Rated Current (PM OLV)
Sets the motor rated current in amps.
No. Parameter Name Setting Range Default
E5-03 Motor Rated Current
10 to 200% of drive rated
current
Depending on
E5-01
Note: 1. The resolution of E5-03 depends on the rated output power of the drive. If a drive is set up for 7.5 kW rated output power (ND or HD
rating) the value will have two decimal places. It will have one decimal place if a drive is set up for 11 kW and higher.
2. This parameter is not reset when the drive is initialized using A1-03.
n
E5-04: Number of Motor Poles (PM OLV)
Sets the number of motor poles.
5.5
E: Motor Parameters
152
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
