Table D.6 Recommended Input Fuse Selection
VZA
Fuse Type Fuse Fuse Ampere Rating
200 V Class Single-Phase Drives
B0P1
Time Delay Class RK5 Fuses
600 Vac, 200 kAIR
TRS5R 5
B0P2 TRS10R 10
B0P4 TRS20R 20
B0P7 TRS35R 35
B1P5 TRS50R 50
B2P2 TRS60R 60
B4P0
Non-Time Delay Class J
Fuses
600 Vac, 200 kAIR
A6T100 100
200 V Class Three-Phase Drives
20P1
Time Delay Class RK5 Fuses
600 Vac, 200 kAIR
TRS5R 5
20P2 TRS5R 5
20P4 TRS10R 10
20P7 TRS15R 15
21P5 TRS25R 25
22P2 TRS35R 35
24P0 TRS60R 60
25P5
Non-Time Delay Class J
Fuses
600 Vac, 200 kAIR
A6T110 110
27P5 A6T150 150
2011 A6T200 200
2015 A6T225 225
400 V Class Three-Phase Drives
40P2
Time Delay Class RK5 Fuses
600 Vac, 200 kAIR
TRS2.5R 2.5
40P4 TRS5R 5
40P7 TRS10R 10
41P5 TRS20R 20
42P2 TRS20R 20
43P0 TRS20R 20
44P0 TRS30R 30
45P5
Non-Time Delay Class J
Fuses
600 Vac, 200 kAIR
A6T60 60
47P5 A6T70 70
4011 A6T110 110
4015 A6T125 125
n
Low Voltage Wiring for Control Circuit Terminals
Wire low voltage wires with NEC Class 1 circuit conductors. Refer to national state or local codes for wiring. Use a class
2 (UL regulations) power supply for the control circuit terminal.
Table D.7 Control Circuit Terminal Power Supply
Input / Output Terminal Signal Power Supply Specifications
Multi-function photocoupler output P1, P2, PC Require class 2 power supply
Multi-function digital inputs S1, S2, S3, S4, S5, S6, SC
Use the internal power supply of the drive. Use class 2
for external power supply.
Multi-function analog inputs A1, A2, AC
Use the internal power supply of the drive. Use class 2
for external power supply.
Pulse train input RP
Use the internal LVLC power supply of the drive. Use
class 2 for external power supply.
Pulse train output MP
Use the internal LVLC power supply of the drive. Use
class 2 for external power supply.
n
Drive Short-Circuit Rating
This drive has undergone the UL short-circuit test, which certifies that during a short circuit in the power supply the current
flow will not rise above 30,000 amps maximum at 240 V for 200 V class drives and 480 V for 400 V class drives.
• The MCCB and breaker protection and fuse ratings shall be equal to or greater than the short-circuit tolerance of the
power supply being used.
• Suitable for use on a circuit capable of delivering not more than 30,000 RMS symmetrical amperes for 240 V in 200 V
class drives (up to 480 V for 400 V class drives) motor overload protection.
u
Drive Motor Overload Protection
Set parameter E2-01 (motor rated current) to the appropriate value to enable motor overload protection. The internal motor
overload protection is UL listed and in accordance with the NEC and CEC.
D.3
UL Standards
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
