Omron V1000 User Manual

4.4 Start-up Flowcharts
The flowcharts in this section summarize basic steps required to start the drive. Use the flowcharts to determine the most
appropriate start-up method for a given application. The charts are intended as a quick reference to help familiarize the
user with start-up procedures.
Flowchart Subchart Objective Page
A Basic startup procedure and motor tuning. 77
A-1 Simple motor setup with Energy Savings or Speed Search using V/f mode. 78
A-2 High-performance operation using Open Loop Vector (OLV) motor control. 79
A-3 Operation with Permanent Magnet (PM) motors. 80
-
Setup of drive using application specific selections. Refer to Application Selection on page
82.
-
4.4 Start-up Flowcharts
76
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
